Product Lines
High Efficiency Comfort Systems
| MODEL | Configuration | Input MBtuH | Output MBtuH | AFUE | CFM | Dimensions HxWxD | Weight Lbs. |
|---|---|---|---|---|---|---|---|
| 80G1DF045AP12 | Downflow | 44.0 | 35.2 | 80.0 | 1465 | 33x14.5x28.4 | 112 |
| 80G1DF070AP12 | Downflow | 66.0 | 52.8 | 80.0 | 1506 | 33x14.5x28.4 | 121 |
| 80G1DF090BP16 | Downflow | 88.0 | 70.4 | 80.0 | 1864 | 33x17.5x28.4 | 140 |
| 80G1DF110CP20 | Downflow | 110.0 | 88.0 | 80.0 | 2416 | 33x21x28.4 | 163 |
| 80G1UH045AP12 | Upflow / Horizontal | 44.0 | 35.0 | 80.0 | 1571 | 33x14.5x28.4 | 110 |
| 80G1UH070AP08 | Upflow / Horizontal | 66.0 | 54.0 | 80.0 | 1113 | 33x14.5x28.4 | 114 |
| 80G1UH070AP12 | Upflow / Horizontal | 66.0 | 54.0 | 80.0 | 1579 | 33x14.5x28.4 | 119 |
| 80G1UH090BP12 | Upflow / Horizontal | 88.0 | 70.0 | 80.0 | 1724 | 33x17.5x28.4 | 131 |
| 80G1UH090BP16 | Upflow / Horizontal | 88.0 | 71.0 | 80.0 | 1911 | 33x17.5x28.4 | 183 |
| 80G1UH110CP12 | Upflow / Horizontal | 110.0 | 89.0 | 80.0 | 1625 | 33x21x28.4 | 144 |
| 80G1UH110CP16 | Upflow / Horizontal | 110.0 | 89.0 | 80.0 | 2078 | 33x21x28.4 | 151 |
| 80G1UH110CP20 | Upflow / Horizontal | 110.0 | 89.0 | 80.0 | 2420 | 33x21x28.4 | 161 |
| 80G1UH135DP20 | Upflow / Horizontal | 132.0 | 107.0 | 80.0 | 2120 | 33x24x28.4 | 174 |
Warranty Information
- All Parts for 120 months -
- Heat Exchanger - Limited Lifetime
Available Documents
- View Document (Consumer Literature, Color)
- View Document (Specification Sheet, Technical Information)
