Product Lines
High Efficiency Comfort Systems
| MODEL | Cooling Cap. MBtuH | SEER | Heating Cap.MBtuH | HSPF | Refrigerant Charge Oz. | Line Size | Dimensions HxWxD | Weight Lbs. |
|---|---|---|---|---|---|---|---|---|
| 4SHP14LE118P | 18.0 | 14.0 | 17.0 | 8.2 | 93 | 3/8-3/4 | 29.25x31.25x37.75 | 175 |
| 4SHP14LE124P | 23.4 | 14.0 | 21.6 | 8.2 | 94 | 3/8-3/4 | 29.25x31.25x37.75 | 177 |
| 4SHP14LE130P | 28.0 | 14.0 | 25.0 | 8.2 | 90 | 3/8-3/4 | 29.25x31.25x37.75 | 178 |
| 4SHP14LE136P | 34.0 | 14.0 | 33.8 | 8.2 | 150 | 3/8-7/8 | 29.25x31.25x33.75 | 202 |
| 4SHP14LE142P | 41.0 | 14.0 | 40.0 | 8.2 | 184 | 3/8-7/8 | 35.75x37.75x37.75 | 272 |
| 4SHP14LE148P | 47.0 | 14.0 | 46.0 | 8.2 | 161 | 3/8-7/8 | 35.75x37.75x37.75 | 273 |
| 4SHP14LE160P | 57.0 | 14.0 | 55.0 | 8.2 | 197 | 3/8-7/8 | 35.75x37.75x43.75 | 297 |
Warranty Information
- All Parts for 120 months - With prompt online registration
- Compressor for 120 months -
Available Documents
- View Document (Consumer Literature, Color)
- View Document (Specification Sheet, Technical Information)
